【Chassis Parameters】
JAC cab chassis, condition new, single cabin, 3 seats, 3360mm wheelbase, Cummins 125HP Euro 3 dieseI engine, WLY 6-speed transmission, 7.00R16 radial tires, with one spare tire, 2.5 Ton front axle, 4.5 Ton rear axle, air brake, power assist steering, etc.
Chassis brand options: Dongfeng, Sinotruk HOWO, Foton, JAC, SHACMAN, SAIC-HONGYAN-IVECO, etc.
【Upper Structure Parameters】
Insulation box size 4150x1900x2000mm, total 15 cubic meter box volume; insulation box material outer and inner plate are FRP panel, middle with 80mm insulation layer; Refrigeration unit is American import Thermo King -15℃ capacity.
Refrigeration unit brand options: American import brand Thermo King, Carrier brand; China brand Hanxue, Kauxue, Huatai, Bingli, etc.
Model | CLW5060XLCHF3 |
Chassis brand | JAC |
Wheeldrive | 4x2, LHD |
New or Used | New |
Overall dimension(mm) | 5995x2150x2985 |
Insulation box dimension(mm) | 4150x1900x2000 |
Material of Insulation box | Sanwitch structure: FRP panel + 80mm insulation + FRP panel |
Refrigeration unit |
Bingli -15~0 ℃ |
Gross weight(kg) | 7360 |
Curb weight(kg) | 2800 |
Load Weight(kg) | 4-5 tons |
Wheelbase(mm) | 3360 |
Engine power | Cummins 125HP Euro3 |
Fuel type | DieseI |
Transmission | WLY 6- speed |
Brake | Air brake |
Axle load(front/rear) | 2.5/4.5 tons |
Tire | 6+1 pcs, 7.00R16 radial tires |
Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
