【Chassis Parameters】
Chassis parameters of JMC 10m scissor lift platform truck: JMC brand new cab chassis, condition new, doube cabin, 3+3 seats, 3360mm wheelbase, Jiangling 77HP Euro2 dieseI engine, Manual 5-speed transmission, 7.0016 tires, with one spare tire, 2 ton front axle, 3.5 ton rear axle, oil brake, power assist steering, with air conditioning, etc.
【Upper Structure Parameters】
Superstructure parameters of JMC 10m scissor lift platform truck:
Lifting platform truck is a lifting mechanical equipment used for high-altitude operation and maintenance. The product has the characteristics of stable structure, flexible movement, stable lifting, convenient operation and large carrying capacity. Provides convenience for aerial work units.
The scissor lift platform truck is a kind of vertical lift, which is widely used indoors and outdoors for special equipment for aerial work. It can be widely used for equipment maintenance, indoor and outdoor mechanical installation, equipment maintenance and building maintenance in stations, docks, bridges, halls, workshops.
Features of scissor lift platform: It is mainly used in logistics industry, production line, cargo lifting, loading and unloading between basement and floor, and can also be used for lifting stage, lifting console, etc. The product has stable structure, low failure rate, reliable operation, safety and efficiency, and simple and convenient maintenance.
| Vehicle Basic Specifications |
|||
| Vehicle Model | CLW5040JGKJX2 | Maximum Working Height | 10 meters |
| Chassis brand | JMC 4x2 | New or Used | Condition new |
| Overall dimension | 5995x2100x2860mm | Cargo Box Dimension | 2300x1880x450mm |
| Gross weight | 4495 kg | Rated Weight | - |
| Curb weight | 3850 kg | Wheelbase | 3360mm |
| Axle No. | 2 | Cab Seat No. | 3 |
| Axle Load | 2000/3500 kg | Fuel Type | Diesel |
| Engine | Jiangling 77hp Euro2 | Steering System | LHD, power aissist steering |
| Transmission | Manual 5- speed | Clutch | Single dry clutch plate |
| Brake | Air brake | Tire No. | 6 +1 pcs |
| Front/Rear Suspension | - | Tire Model | 7.00R16 |
| Fuel Tank | 100 liter | Battery | 12V/24V |
| Max speed | 80km/h |
||
| Superstructures Parameters |
|||
| Model | CLW SJPT10J | Maximum Working Height | 10 meters |
| Type | Scissor hydraulic lifting | Platform Load | 400 kg |
| Outrigger | 2 pcs hydraulic outriggers | ||
| Features |
Chengli CLW brand aerial work truck is simple in structure, sturdy and durable, easy to operate and reliable. The unique hydraulic control system design makes the staff operate more smoothly, and can send the staff to the heights of 8 meters, 10 meters and 12 meters more safely for maintenance, installation, cleaning, photography, shipbuilding, chemical industry, electricity, pruning , replacement of street lights and other works for repairs. |
||
【Customers Feedback】
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
