Chengli 60m3/h fuel pump for 10-25 ton large fuel tank trucks

- Pump Model: 80YHCB-60
- Medium: diesel,petrol,etc
- Flow: 60m3/h
- Head: 80 meter
- Rotary: 970 rpm
- Suction height: 6 meter
- Whatsapp/wechat:+8618307220638
- Email:[email protected]
- Http://

80HYCB-60 Large Flow Fuel Pump for Large Fuel Tanker Trucks
(Suitable for dongfeng fuel truck,howo fuel truck,foton fuel truck,isuzu fuel truck,faw fuel truck,jac fuel truck,etc)

Chengli 80HYCB-60 large flow fuel pump is applicable to large fuel tank trucks of about 10-25 tons capacity, stable performance, good price.
Model 80HYCB-60
Medium for diesel, petrol,Kerosene,lubricating oil,etc
Type Gear type fuel pump
Brand CLW
New or Used New
Flow 60m3/h (1000 L/min)
Head Height 80 meter
Input Shaft Speed 970 rpm
Shaft Power 11(kW)m
Suction Height 6 meter
Input Shaft Rotary Direction Left or Right
Pressure 0.6MPa
Packing Weight -
Packing Dimension -
Package Wood Box

Use Special Reminder:

1、 If the fuel pump is not full of medium, it is strictly forbidden to start the PTO(power take-off) control handle, otherwise the gear will be burnt.

2、 When the temperature is lower than ℃, the oil in the fuel pump must be drained after the work is completed, otherwise the fuel pump box will be damaged due to freezing.

3、 Hard objects shall be strictly prevented from entering the fuel pump body to damage the gears. If the fuel pump cannot rotate, special personnel shall be assigned to repair it.

4、 The user shall be responsible for the loss caused by the above reasons. YHCB series circular arc gear oil pump is mainly used to transport oil with viscosity of 5~15,000m3/s, temperature below 80 ℃, no solid particles and fibers, lubricating oil and media similar to this kind of oil. Such as automobile, kerosene, diesel and mechanical lubricating oil. It is an ideal pump for oil tank trucks and oil departments.

Installation, Sse and Maintenance of Fuel Pump:

1、 The fuel pump can be installed in the refueling truck and the fuel pump room of the oil depot. The design of the oil circuit installed on the truck shall comply with the functions specified in Article 4.18.1 of GB9414-88. The oil circuit diagram shown in this manual is for reference only. If a four-way valve is equipped, the oil circuit is more convenient.

2、 Precautions for installation and use on the fuel refilling truck: (1) The fuel pump is driven by the power take-off and transmission shaft of the automobile gearbox. The fuel pump should be installed as far forward as possible. The pump shaft and transmission shaft should be coaxial as far as possible, and the inclination angle should not be greater than 70. (2) Fuel pump should be hoisted on a hanger welded with angle steel. The height of the pump can be determined according to the axis of the output shaft of the power take-off. The left and right positions of the pump should be close to the longitudinal beam of the automobile as possible, To avoid interference between the pump and the automobile transmission shaft. And fix it on the car longitudinal beam with bolts. (3) The diameter of the suction pipe mouth shall be matched with the diameter of the fuel pump inlet and outlet, and the suction shall be vertical to the longitudinal beam of the vehicle. The vertical depth of suction shall not be greater than 7m, and the pipeline shall be shortened as far as possible. (4) During operation, the pressure gauge does not rise above 0.5MPa, and the vacuum gauge does not rise above -0.08 MPa.

3、 Before running the fuel pump, verify the rotation direction of the drive shaft, the sealing of the flange and the joint, carefully check whether the valve switches are correct, and do not start the oil pump when the valve of the pump outlet pipeline is not opened, so as to avoid damage to components and danger.

4、 Clean the filter regularly (half a month) to avoid blocking and affecting the pump flow. Regularly check and adjust the oil discharge pressure of the safety valve. The diameter of suction pipe orifice must be equal to that of outlet pipe. 5、 The pump speed should be low to high, accelerate slowly, and maintain the corresponding speed. It is not allowed to overspeed at will, nor to change from high to low.

6、 During the operation of the gear fuel pump, pay attention to the counting of the pressure gauge and vacuum gauge. If the pressure counting is too large, it means that the lift is too high or the pump outlet pipeline is blocked, which causes overload. If the vacuum gauge is large, it means that the suction head is too large or the pump suction pipe is blocked, which causes cavitation of the pump.

7、 In low temperature season, when the pump is not working, the liquid stored in the pump should be drained from the hole to prevent the box from freezing and cracking.

8、 If the pump is used for a long time, it shall be properly protected against rust.

9、 The bearing shall be filled with calcium base grease (referring to large flow pump) every six months.

10、 The pipeline shall have a pipe rack. The pump is not allowed to bear the load of the pipeline. The pump installation height shall not exceed the allowable vacuum suction height when the pump is working.

11、 When stopping, disconnect the power take-off handle first, and then close the inlet and outlet valves of the pump.

12、 If the pump is not full of medium, it is strictly prohibited to start.

13、 During installation, avoid striking the driving shaft or coupling axially, otherwise the gear will be damaged due to friction between the gear and the box.

Suitable Fuel Tank Trucks Models for
80HYCB-60 Fuel Pump:

Packing & Shipping of Water Pump:

Chengli Special Automobile Co., Ltd. Has a Complete After-sales Service System

In order to make you always satisfied from purchasing, owning and using products, Chengli Special Automobile Co.,Ltd has a nationwide sales and service network to provide you with a full range of services.

◆Training Service

Jiangnan Company provides free expert training for all customers who purchase our products, and the training does not charge any fees.

◆Warranty Commitment

Customers can enjoy up to one year or 25,000 kilometers, and free replacement of parts (excluding wearing parts) damaged due to quality problems during the warranty period. The chassis part is guaranteed by the original factory at the national secondary service station nationwide, and the modified part is provided by our company with the service tenet of the customer being always right, and the service tenet of "customer care and caring for each car". Respond within 12 hours after receiving the letter for help from customers, and do not exceed 24 hours for door-to-door service in inland provinces and cities, and 48 hours for individual areas. Long-term supply of original accessories and accessories to provide accessories at preferential market prices. Overseas customers guarantee to reply within 24 hours and give guidance plan.

◆24 Hours Service

The service tenet is that the customer is always right, the service tenet is to care about the customer and every car, and make a public commitment to the society. , Shanghai, Guangdong, Zhejiang, Fujian, Hainan), no more than 24 hours in inland provinces and cities, and no more than 48 hours in individual areas.

◆Rescue Service

When the customer's vehicle cannot be repaired at the service station due to special reasons, the service station can provide on-site service of vehicles, personnel and accessories to solve the customer's difficulties to the greatest extent and reduce the customer's concerns about using the car.

◆Customer Return Visit

Chengli Special Automobile Co.,Ltd. implements the three-level return visit service of dealers, service stations and return visit consultants, caring about customers, helping customers understand and familiarizing themselves with cars, helping customers to actively digest potential hidden dangers in advance, and improving the effective service life of products. To ensure the interests of customers.

Order Process

     ①: Car purchase negotiation: Contact the vehicle model information parameters by telephone or on-site inspection to discuss the vehicle model, Beiqi Foton remote water supply forest fire truck price and related requirements.

     ②: Signing the contract: Both parties sign the vehicle purchase and sale contract and pay the contract deposit in advance (fax signing of the contract or on-site signing of the contract is acceptable).

     ③: Arrange production: Our company arranges workshop production according to the contract requirements.

     ④: Delivery of the vehicle: The vehicle is delivered and accepted, the balance of the vehicle is paid, and the relevant procedures are completed. For more detailed car booking process, please inquire!

Answers to the Questions that Customers Care About before Purchasing?

(1) Free maintenance plan and period?

1. Tracking service time: lifetime; 2. From the date of delivery to the customer, within the normal range of use, within 20,000 kilometers or within one year of free repair (excluding wearing parts and electrical parts), more than one year, only charge Parts fee; 3. Service arrival time: within the province, arrive within 24 hours; other areas, dispatch personnel within 24 hours; 4. During the annual flood control period, engineers and technicians are scheduled to visit regularly or irregularly to ensure timely failures Excluded, no fault active prevention.

(2) What is the price method of free post-parts supply?

1. Method: unified supply at the local Dongfeng/Jinan Heavy Duty Truck/Isuzu and other chassis technical service stations, according to user requirements or directly delivered by Chengli Special Automobile Factory; 2. Parts are only charged for the cost of production, and no other fees are added.

(3) After-sales service method?

The maintenance of the chassis part can be solved at the service station near the user's place of use. The maintenance of the special device can be done by telephone or fax. The supplier will send professional maintenance personnel to the place of use 24-28 hours after receiving the call from the user.

(4) Technical training program?

The supplier is responsible for free training of equipment users at the user's location before delivering the vehicle to the user, mainly on how to operate the hydraulic system and special devices for the driver to be familiar with the basic principles of this type of vehicle and the ability to deal with general failures.

(5) How to transport and load the vehicle?

According to the dimensions and weight of the vehicle or cargo, you can choose bulk carriers, ro-ro ships, container ships 20GP, 40GP, 40HQ, 40FR, etc.

(6) What is the time to pick up the car at the factory?

Self-pick-up time: Monday to Sunday, 08:00-19:00 (some self-pick-up points work hours from 9:00-18:00, in case of national holidays, the press release time shall prevail. focus on)

(7) Can't we go to China abroad? Want to see the car to see the factory how to do?

We can let users see the general situation of offices, factories, production scenes, and factories through video calls and shooting videos, and help foreign customers understand us. For users who order vehicles, they can watch the vehicle appearance, function demonstration videos, and other details through video inspection, so that users can grasp their order production progress and situation in real time. We will create high-quality and personalized special vehicles for each user according to the actual needs of users. You are welcome to visit the production strength and product technology on the spot, and we will provide you with the best service!

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
