China Benz Beiben 20000 liter Aircraft Refueler Aviation Kerosene Fuel Refueling Tanker Truck

- Brand: BEIBEN
- Engine:Weichai 340HP
- Volume:20000 liter
- Medium:aviation kerosene
- Filter:Jet fuel kerosene filter separator
- Whatsapp/mob:+8618307220638
- Email:[email protected]
- Website:www.cnclwgr

【Contact Us】

Chengli Special Automobile Co.,Ltd

Whatsapp/Wechat: +8618307220638

E-mail: [email protected]


Add: South Suburb Chengli Automobile Industry Park, Suizhou City, Hubei Province, China


【Chassis Parameters】

Chassis of China Benz Beiben 20000 liter Aircraft Refueler Aviation Jet Fuel Refueling Tanker Truck: Beiben 6x4 chassis, condition new, 4350+1350mm wheelbase, Weichai WP10.340E32 340HP Euro2 diesel engine, Fast 10-speed transmission, 12.00R20 radial tires, with one spare tire, 7.5 ton front axle, 2x 16 ton rear axle, air brake, power assist steering, air brake, exhaust pipe front mounted, with air conditioning, etc.

【Upper Structure Parameters】

● Features of China Benz Beiben 20000 liter Aircraft Refueler Aviation Jet Fuel Refueling Tanker Truck

The aircraft refueling truck is basically the same as the ordinary refueling truck in general, but there are some special requirements in performance and structure.

1. High requirements for refueling pressure stability. For this purpose, add a pressure regulator, a pressure regulator and a pressure filling gauge to the filling line.

2. The cleanliness of the oil is high. High-performance filter separators should be used on the oil circuit. Tanks and pipes must be made of aluminum alloys.

3. Absolutely guarantee the safety of refueling. Antistatic devices, interlocking control systems, electrical explosion-proof devices, fire extinguishers, etc. should be installed.

4. Equipped with high-precision, large-flow meter.

5. The total capacity of the oil tank is large, and the refueling of the aircraft should be completed at one time. For example, the capacity of WG series tank tanker is 10,000, 15,000, 18,000, 20,000, 22,000, 45,000L, and the capacity is dozens or even hundreds of times that of ordinary truck fuel tanks.


【Vehicle Basic Parameters】

Vehicle Basic Specifications
Vehicle Model CLW5260GJYB2 Volume of Tanker 20000 liter
Chassis brand Beiben New or Used  Condition new
Overall dimension 9985x2500x3850mm Cargo Box Dimension  -
Gross weight 26000 kg Rated Weight 10500
Curb weight 15500 kg Wheelbase 4500 mm
Axle No. 3 Cab Seat No. 3 people
Axle Load 7500/2x16000 kg Fuel Type Diesel
Engine Weichai WP10.340E32 340HP Steering System LHD, power aissist steering
Transmission Manual 10-speed Clutch Single dry clutch plate
Brake Air brake Tire No. 10 +1 pcs
Front/Rear Suspension - Tire Model 12.00R20 radial tires
Fuel Tank 400 liter Battery 24V
Max speed 90km/h
Superstructures Parameters
Type Aircraft refueling specially Volume of Tanker 20,000 liter
Medium Aviation kerosene Material of Tanker Aluminum alloy
 Manhole 1 pcs, aluminum alloy manhole cover Fuel Discharge Valve

1 pcs

 Safety Valve Bottom emergency cut off valve, breathing valve, anti-overflow probe  Filter Separator

1 unit aviation jet fuel fitler separator

Rated Flow: 50m³/h

Joint Valve

HYJ63 joint valve Filter separator outlet sampling valve

1 pcs

Flow Meter

1 pcs Level Guage

1 pcs


Pump inlet and pump outlet, aviation kerosene dedicated aluminum alloy fuel pump

Refueling Device

Refueling nozzle with 30 meter thick hose reel

Refueling Device Compartment

Safety System

1. Foot emergency cut-off valve;

2. Breathing valve;

3. Anti-overflow probe;

4. Static conductive wire reel;

5. Fire extinguisher.

 Chengli Special Automobile Co., Ltd. Has a Complete After-sales Service System

In order to make you always satisfied from purchasing, owning and using products, Chengli Special Automobile Co.,Ltd has a nationwide sales and service network to provide you with a full range of services.

◆Training Service

Jiangnan Company provides free expert training for all customers who purchase our products, and the training does not charge any fees.

◆Warranty Commitment

Customers can enjoy up to one year or 25,000 kilometers, and free replacement of parts (excluding wearing parts) damaged due to quality problems during the warranty period. The chassis part is guaranteed by the original factory at the national secondary service station nationwide, and the modified part is provided by our company with the service tenet of the customer being always right, and the service tenet of "customer care and caring for each car". Respond within 12 hours after receiving the letter for help from customers, and do not exceed 24 hours for door-to-door service in inland provinces and cities, and 48 hours for individual areas. Long-term supply of original accessories and accessories to provide accessories at preferential market prices. Overseas customers guarantee to reply within 24 hours and give guidance plan.

◆24 Hours Service

The service tenet is that the customer is always right, the service tenet is to care about the customer and every car, and make a public commitment to the society. , Shanghai, Guangdong, Zhejiang, Fujian, Hainan), no more than 24 hours in inland provinces and cities, and no more than 48 hours in individual areas.

◆Rescue Service

When the customer's vehicle cannot be repaired at the service station due to special reasons, the service station can provide on-site service of vehicles, personnel and accessories to solve the customer's difficulties to the greatest extent and reduce the customer's concerns about using the car.

◆Customer Return Visit

Chengli Special Automobile Co.,Ltd. implements the three-level return visit service of dealers, service stations and return visit consultants, caring about customers, helping customers understand and familiarizing themselves with cars, helping customers to actively digest potential hidden dangers in advance, and improving the effective service life of products. To ensure the interests of customers.

Order Process

     ①: Car purchase negotiation: Contact the vehicle model information parameters by telephone or on-site inspection to discuss the vehicle model, Beiqi Foton remote water supply forest fire truck price and related requirements.

     ②: Signing the contract: Both parties sign the vehicle purchase and sale contract and pay the contract deposit in advance (fax signing of the contract or on-site signing of the contract is acceptable).

     ③: Arrange production: Our company arranges workshop production according to the contract requirements.

     ④: Delivery of the vehicle: The vehicle is delivered and accepted, the balance of the vehicle is paid, and the relevant procedures are completed. For more detailed car booking process, please inquire!

Answers to the Questions that Customers Care About before Purchasing?

(1) Free maintenance plan and period?

1. Tracking service time: lifetime; 2. From the date of delivery to the customer, within the normal range of use, within 20,000 kilometers or within one year of free repair (excluding wearing parts and electrical parts), more than one year, only charge Parts fee; 3. Service arrival time: within the province, arrive within 24 hours; other areas, dispatch personnel within 24 hours; 4. During the annual flood control period, engineers and technicians are scheduled to visit regularly or irregularly to ensure timely failures Excluded, no fault active prevention.

(2) What is the price method of free post-parts supply?

1. Method: unified supply at the local Dongfeng/Jinan Heavy Duty Truck/Isuzu and other chassis technical service stations, according to user requirements or directly delivered by Chengli Special Automobile Factory; 2. Parts are only charged for the cost of production, and no other fees are added.

(3) After-sales service method?

The maintenance of the chassis part can be solved at the service station near the user's place of use. The maintenance of the special device can be done by telephone or fax. The supplier will send professional maintenance personnel to the place of use 24-28 hours after receiving the call from the user.

(4) Technical training program?

The supplier is responsible for free training of equipment users at the user's location before delivering the vehicle to the user, mainly on how to operate the hydraulic system and special devices for the driver to be familiar with the basic principles of this type of vehicle and the ability to deal with general failures.

(5) How to transport and load the vehicle?

According to the dimensions and weight of the vehicle or cargo, you can choose bulk carriers, ro-ro ships, container ships 20GP, 40GP, 40HQ, 40FR, etc.

(6) What is the time to pick up the car at the factory?

Self-pick-up time: Monday to Sunday, 08:00-19:00 (some self-pick-up points work hours from 9:00-18:00, in case of national holidays, the press release time shall prevail. focus on)

(7) Can't we go to China abroad? Want to see the car to see the factory how to do?

We can let users see the general situation of offices, factories, production scenes, and factories through video calls and shooting videos, and help foreign customers understand us. For users who order vehicles, they can watch the vehicle appearance, function demonstration videos, and other details through video inspection, so that users can grasp their order production progress and situation in real time. We will create high-quality and personalized special vehicles for each user according to the actual needs of users. You are welcome to visit the production strength and product technology on the spot, and we will provide you with the best service!

*Visit and for more details about 5000 liter fuel tank truck and Fuel Tank Truck Series. If you need any help, send us a meesage to [email protected] or directly contact us thru whatsapp +8618307220638 for instant communication.
