【Chassis Parameters】
Dongfeng 4x2 heavy cab chassis, condition new, classical cabin, 3 seats with half sleeper, 4500mm wheelbase, Cummins 190HP Euro 3 dieseI engine, manual 8-speed transmission, 6+1 pcs 10.00R20 radial tires, with one spare tire, 5 Ton front axle, 10 Ton single reduction rear axle, air brake, power assist steering, with air conditioning, etc.
【Upper Structure Parameters】
Cargo box size 6000x2350x(600mm+1200mm high fence), high fence with opening doors; cargo box material 2mm side, 3mm floor.
Model | CLW5160TZHD3 |
Chassis brand | Dongfeng |
Wheeldrive | 4x2, LHD |
New or Used | New |
Overall dimension(mm) | 8350x2500x3200 |
Dump box dimension(mm) | 6000x2350x(600+1200) |
Material of dump box | carbon steel, 2mm side, 3mm floor |
Gross weight(kg) | 16000 |
Curb weight(kg) | 6800 |
Load Weight(kg) | 10~15 tons |
Wheelbase(mm) | 4500 |
Engine power | Cummins 190HP Euro3 |
Fuel type | DieseI |
Transmission | HW19710 manual 10- speed |
Brake | Air brake |
Axle load(front/rear) | 5/10 tons |
Tire | 10+1 pcs, 10.00R20 radial tires |
Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
