Dongfeng 20000 liter Aluminum Fuel Tank Truck

Dongfeng 20,000 liter Aluminum Fuel Tank Truck
Cummins 210HP or Yuchai 260HP
Tire: 8+1 pcs 10.00R20 radial tire
Tank: 6mm aluminum alloy, 7mm tank head
Valve: API joint discharge valve, Euro standard manhole cover, safety valve, etc.

【Contact Us】

Chengli Special Automobile Co.,Ltd

Whatsapp/Wechat: +8618307220638

E-mail: [email protected]


Add: South Suburb Chengli Automobile Industry Park, Suizhou City, Hubei Province, China


【Chassis Parameters】

Chassis of Aluminum Alloy Fuel Tank Truck: Dongfeng 6x2 chassis, condition new, 1800+4350mm wheelbase, Cummins 210HP or Yuchai 260HP diesel engine, Fast 8-speed transmission, 10.00R20 radial tires, with one spare tire, 5 ton front axle, 10 ton rear axle, air brake, power assist steering, air brake, exhaust pipe front mounted, etc.


【Upper Structure Parameters】

Chengli oil tanker, oil tanker: also known as mobile refueling truck, fuel tank truck, fuel tanker truck, computer tax-controlled refueling truck, oil tanker, oil loading truck, oil truck, oil truck, oil transporter, edible oil transporter, mainly used for oil Transportation and storage of derivatives (gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products). According to different uses and use environments, it has a variety of refueling or oil transportation functions, including oil absorption, pumping oil, and various oil packaging and distribution functions.

Chengli fuel tank truck capacity: chengli produced fuel tanker volume from 1000 liter to 60000 liter, tanker truck, tanker trailer, tanker container, etc. We accept customzied services and designeds.

Chengli fuel tank truck has: dongfeng fuel tank truck,howo fuel tanker,shacman oil tanker truck,isuzu fuel tanker truck,foton fuel tank truck,iveco fuel truck,jac oil tank truck,etc.


【Vehicle Basic Parameters】

Vehicle Basic Specifications
Vehicle Model CLW5250GJYD3 Volume of Tanker 20000 liter
Chassis brand Dongfeng 6x2 New or Used  Condition new
Overall dimension 9850x2500x30500mm Cargo Box Dimension  -
Gross weight 25000 kg Rated Weight 16500 kg
Curb weight 8500 kg Wheelbase 1800+4350 mm
Axle No. 3 Cab Seat No. 3 people, with a sleeper
Axle Load 6500/6500/12000 kg Fuel Type Diesel

Cummins 210HP Euro3

Yuchai 260HP Euro3

Steering System LHD, power aissist steering
Transmission Manual 8-speed Clutch Single dry clutch plate
Brake Air brake Tire No. 8 +1 pcs
Front/Rear Suspension - Tire Model 10.00R20 radial tires
Fuel Tank 350 liter Battery 24V
Max speed 90km/h
Superstructures Parameters
Type Fuel Transport Tanker Volume of Tanker 20,000 liter
Medium Gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products Material of Tanker Aluminum alloy
 Manhole 2 pcs, aluminum alloy manhole cover Fuel Discharge Valve

2 pcs

 Safety Valve Bottom emergency cut off valve, breathing valve, anti-overflow probe Pump

1 unit, 60/90 fire pump

Pump inlet and pump outlet

Flow Meter

Optional  Level Guage Optional
Refueling Device

Refueling nozzle with 15 meter thick hose reel  (optional)

Safety System

1. Foot emergency cut-off valve;

2. Breathing valve;

3. Anti-overflow probe;

4. Static conductive wire reel;

5. Fire extinguisher.


*Visit and for more details about 5000 liter fuel tank truck and Fuel Tank Truck Series. If you need any help, send us a meesage to [email protected] or directly contact us thru whatsapp +8618307220638 for instant communication.
