【Chassis Parameters】
Dongfeng DFAC 4x2 chassis, single cabin, condition new, 3800mm wheelbase, Yuchai 140HP Euro3 diesel engine, manual 6-speed transmission, 8.25R20 radial tires, with one spare tire, 2.7 ton front axle, 7.2 ton rear axle, air brake, power assist steering, exhaust pipe front mounted, etc.
【Upper Structure Parameters】
Dumper box size 4200x2000x800mm; dump box material 4mm side wall, 6mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Vehicle Basic Specifications | |
| Model | CLW5120ZZXD3 |
| Chassis brand | Dongfeng |
| Wheeldrive | 4x2 LHD |
| New or Used | New |
| Overall dimension(mm) | 6450x2250x2680 |
| Dump box dimension(mm) | 4200x2000x800 |
| Gross weight(kg) | 11995 |
| Curb weight(kg) | 6850 |
| Designed Load | 8 tons |
| Wheelbase(mm) | 3800 |
| Engine power | Yuchai 140HP Euro3 |
| Fuel type | DieseI |
| Transmission | Manual 6- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2.7 tons / 7.2 tons |
| Tire | 6+1 pcs, 8.25R20 radial tires |
| Max speed | 90km/h |
| Vehicle Superstructure Parameters | |
| Dump Box Dimension | 4200x2000x800mm |
| Material | High strengthen carbon steel, 4mm side, 6mm bottom |
| Unloading Method of Dump Box | Double cylinders middle lifting |
| Maximum Dumping Angle | ≤ 45° |
| Back Door | Hinge structure , auto open when dumping |
| Side Opening Door | One(1) |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
