Dongfeng 4x4 3 Ton Dump Truck

- Dongfeng 4x4 RHD 3 TON Dump Truck
- Yunnei 90HP Euro3 engine
- 6+1 pcs 7.00R16 radial tires
- Dump Box: 3800x1900x400mm
- Unloading method of dump box: middle double cylinder lifting jack

【Chassis Parameters】

Dongfeng 4x4 4WD cab chassis, condition new, single cabin, 3 seats, 3300mm wheelbase, Yunnei 90HP Euro 3 dieseI engine, manual 5-speed transmission, 7.00R16 radial tires, with one spare tire, 2 Ton front axle, 3.5 Ton rear axle, air brake, power assist steering, etc.


【Upper Structure Parameters】

Dump box size 3800x1900x400mm;  dump box material 3mm side wall, 4mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.


Model CLW5060ZZXD3
Chassis brand Dongfeng
Wheeldrive 4x4, RHD
New or Used New
Overall dimension(mm) 5800x2050x2230
Dump box dimension(mm) 3800x1900x400
Material of dump box carbon steel, 3mm side, 4mm floor
Unloading method of dump box
middle double cylinder lifting jack
Gross weight(kg) 6800
Curb weight(kg) 3800
Load Weight(kg) 3 tons
Wheelbase(mm) 3300
Engine power Yunnei 90HP Euro3
Fuel type DieseI
Transmission Manual 5- speed
Brake Air brake
Axle load(front/rear) 2/3.5 tons
Tire 6+1 pcs, 7.00R16 radial tires
Max speed 90km/h


As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
