【Chassis Parameters】
Dongfeng 6x4 heavy duty chassis, condition new, 4350+1350mm wheelbase, Yuchai 260HP Euro3 dieseI engine, 9-speed transmission, 10.00R20 radial tires, with one spare tire, 5 ton front axle, 2x 10 ton double reduction rear axle ratio 4.852, full air brake, exhaust brake, power assist steering, power window, central lock, etc.
【Upper Structure Parameters】
Chengli produced garbage compactor body, with 18 cubic meter volume box, rear with waste bin flip device, can flip 120L/240L/660L waste bins, control panel+manual lever+inside cab controlled.
Model | CLW5250ZYSD3 |
Chassis brand | Dongfeng |
Wheeldrive | 6x4, LHD |
New or Used | New |
Overall dimension | 9850x2500x3150mm |
Gross weight | 25000kg |
Curb weight | 11500kg |
Load | 13500kg |
Wheelbase | 4350+1350mm |
Engine power | Yuchai 260HP optional |
Fuel type | DieseI |
Transmission | Manual 9-speed |
Brake | Full air brake, exhaust brake |
Axle load | 5 tons / 2x 10 tons |
Tire | 6+1 pcs, 10.00R20 radial tires |
Max speed | 90km/h |
【Structures & Features of Chengli Garbage Compactor】
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
