【Chassis Parameters】
Dongfeng 6x6 AWD cab chassis, Military Classical Cabin, condition new, 3 seats with a sleeper, 3500+1250mm wheelbase, Cummins 190HP Euro 3 dieseI engine, Manual 6-speed transmission with transfer case (Rear Wheel Drive or All Wheel Drive mode), 12R22.5 off-road tires, with one spare tire, 3,6 Ton front axle, 2x 5 Ton rear axle, air brake, exhaust brake, power assist steering, etc.
Chassis brand options: Dongfeng, Sinotruk HOWO, Foton, JAC, SHACMAN, SAIC-HONGYAN-IVECO, etc.
【Upper Structure Parameters】
Insulation box size 4500x2300x2300mm, total 23.8 cbm box volume; insulation box material outer and inner plate are FRP panel, middle with 80mm insulation layer; Refrigeration unit is China brand -16℃ capacity.
Refrigeration unit brand options: American import brand Thermo King, Carrier brand; China brand Hanxue, Kauxue, Huatai, Bingli, etc.
Model | CLW5120XLCD3 |
Chassis brand | DongFeng |
Wheeldrive | 6x6 AWD |
New or Used | New |
Overall dimension(mm) | 7600x2500x3250 |
Insulation box dimension(mm) | 4500x2300x2300 |
Material of Insulation box | Sanwitch structure: FRP panel + 80mm insulation + FRP panel |
Refrigeration unit |
China famous brand -16℃~ 0 ℃ |
Gross weight(kg) | 12500 |
Curb weight(kg) | 7500 |
Load Weight(kg) | 6~8 tons |
Wheelbase(mm) | 3500+1250 |
Engine power | Cummins 190HP Euro3 |
Fuel type | DieseI |
Transmission | Manual 6- speed |
Transfer Case |
Rear wheel drive mode 6x6 AWD mode |
Brake | Air brake |
Axle load(front/rear) | 3.6T/5T/5T |
Tire | 6+1 pcs, 12R22.5 offroad tyres |
Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
