Water Sprinkler Truck, also called water truck, sprinkler truck, water bowser, water tank truck, water delivery truck, is a kind of sanitation vehicle which has a tank body, manhole cover, water pump, front/rear/side sprinkler nozzles, water cannon and discharge valves, work platform, etc. Water truck can be used for watering tree, grass, cleaning street, dust control, water delivery, emergency fire fighting, etc.
【Chassis Parameters】
Cab chassis of Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck, 153 wide classical cabin, condition new, 3 seats with a sleeper, 3500+1250mm wheelbase, Cummins 210HP Euro3 dieseI engine, manual 6-speed transmission with Dedicated offroad Transfer-Case for 4x2 or 4X4 switch, 6+1 pcs 12R22.5 tires, with one spare tire, 3.5 ton front axle, 2x 6 ton rear axle, air brake, power assist steering, with air conditioning, etc.
【Upper Structure Parameters】
Superstructure of Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck
- Chengli produced water tank & spraying system, multi functional for water delivery, water sprinkling, emergency fire fighting, spray water dust suppression, etc;
- 10,000 liter carbon steel tank, inside with anti-corrosion treatment, with one DN460mm manhole, rear with a platform and ladder;
- with 60m3/h flow water pump;
- with front/rear/side water spraying nozzles, water spraying range 12-16 meters; with a water cannon, spraying range 28 meters;
Specifications of Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck:
| Vehicle Parameters | Model | CLW5180GSS3 |
| New or Used | New | |
| Overall dimension | 8250x2500x3450mm | |
| Gross weight | 18000kg | |
| Curb weight | 8500kg | |
| Chassis Parameters | Chassis brand | DONGFENG OFF-ROAD 6X6 |
| Wheelbase | 3500+1250mm | |
| Engine power | 210HP | |
| Cab | 153 wide Flat roof new cabin, 3 seats | |
| Transmission | Manual, 6-speed forward and 1 reversinf | |
| Front Axle | 3.5 Ton | |
| Rear Axle | 2x 6T , double mount heavy duty | |
| Brake | Air brake, exhaust brake | |
| Tire | 6+1 pcs, 12R22.5 | |
| Max speed | 90km/h | |
| Engine | Brand | Cummins B210-33 |
| Power | 155kW / 210HP | |
| Displacement | 5900cc | |
| Emission standard | Euro 3 | |
| Superstructure | Tank volume | 10,000 liter |
| Tank material | Carbon steel | |
| Front spraying | 2 pcs nozzles, manual or auto controlled | |
| Rear spraying | 2 pcs nozzles, manual or auto controlled | |
| Side spraying | 2 pcs nozzles, manual or auto controlled |
|
| Water cannon | 1 pcs, 360° slewing, shot 28-35 meters | |
| Shot of spraying nozzle | 12 - 16 meters | |
| Valve | 2 pcs, discharge valve + fire hydrant joint |
[Multi-directional Images of Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser truck]
Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck for UN Project:
Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck for UN Project:
Dongfeng offroad 6x6 10000 liter water tender sprinkler bowser tanker truck for UN Project:
Water filling method of BEIBEN 4x4 Offroad 8000 liter water tanker sprinkler truck watertrucks:
Manufacture process of BEIBEN 4x4 Offroad 8000 liter water tanker sprinkler truck watertrucks
Packing list of BEIBEN 4x4 Offroad 8000 liter water tanker sprinkler truck watertrucks
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
