【Chassis Parameters】
FAW (First Automobile Works) 4x4 Dump Truck chassis, FAW single cabin, condition new, 3860mm wheelbase, Yuchai 130HP Euro2 diesel engine, manual 6-speed transmission, TRACAR-25 professional transmission case, 7.50R16 radial tires, with one spare tire, 2.7 ton front axle, 7.0 ton rear axle, air brake, power assist steering, air coditioning, leaf springs no. 10/10+9 pcs, etc.
Other 4x4/6x6/8x8 Offroad chassis brand: Dongfeng 4x4 dump truck,Foton 4x4 dump truck,Howo 4x4 dump truck,Isuzu 4x4 dump truck,SHACMAN 4x4 dump truck,Iveco 4x4 dump truck,etc.
【Upper Structure Parameters】
FAW (First Automobile Works) 4x4 Dump Truck Dumper box size 4300x2000x600mm; dump box material 3mm side wall, 5mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Vehicle Basic Specifications | |
| Model | CLW5100ZZXCA2 4x4 dump truck |
| Chassis brand | FAW(First Automobile Works) |
| Wheeldrive | 4x4 Offroad |
| New or Used | New |
| Overall dimension(mm) | 6500x2250x2850 |
| Dump box dimension(mm) | 4300x2000x600 |
| Gross weight(kg) | 9985 |
| Curb weight(kg) | 4850 |
| Rated load(kg) | 5135 |
| Wheelbase(mm) | 3860 |
| Engine power | Yuchai 130HP Euro2 |
| Fuel type | DieseI |
| Transmission | Manual 6- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2.7 tons / 7.0 tons |
| Tire | 6+1 pcs, 7.50R16 radial tires |
| Max speed | 90km/h |
| Vehicle Superstructure Parameters | |
| Dump Box Dimension | 4300x2000x600mm |
| Material | High strengthen carbon steel, 3mm side, 5mm bottom |
| Unloading Method of Dump Box | Double cylinders middle lifting |
| Maximum Dumping Angle | ≤ 45° |
| Back Door | Hinge structure , auto open when dumping |
| Side Opening Door | One(1) |
FAW (First Automobile Works) 4x4 Dump Truck
FAW (First Automobile Works) 4x4 Dump Truck
FAW (First Automobile Works) 4x4 Dump Truck
Dumper Truck Features & Structures of FAW (First Automobile Works) 4x4 Dump Truck Tipper Truck
Dumper Trucks Tipper Dump Trucks Series
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
