FAW 4x4 Offroad 10 tons Dump Truck Tipper Truck

FAW 4x4 10t Dump Truck
Engine: Weichai 160HP Euro2
Tir: 6+1 pcs 7.50R16 radial tire
Load Capacity: 6 tons
Dump Box: 5400x2200x600mm
Rear dumping: middle double hydraulic cylinders
Description
Description

【Chassis Parameters】

FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck chassis, FAW single cabin, condition new, 5250mm wheelbase, Weichai 160HP Euro2 diesel engine, Fast manual 8-speed transmission, Zhuchi professional transmission case, 11.00R20 radial tires, with one spare tire, 4 ton wheel reduction front axle, 11 ton wheel reduction rear axle, air brake, power assist steering, air coditioning, etc.

 Other 4x4/6x6/8x8 Offroad chassis brand: Dongfeng 4x4 dump truck,Foton 4x4 dump truck,Howo 4x4 dump truck,Isuzu 4x4 dump truck,SHACMAN 4x4 dump truck,Iveco 4x4 dump truck,etc.

【Upper Structure Parameters】

FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck Dumper box size 5400x2200x600mm;  dump box material 4mm side wall, 6mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.



Vehicle Basic Specifications
Model CLW5160ZZXCA2 4x4 dumper truck
Chassis brand FAW(First Automobile Works)
Wheeldrive 4x4 Offroad
New or Used New
Overall dimension(mm) 7680x2480x3000
Dump box dimension(mm) 5400x2200x600
Gross weight(kg) 16000
Curb weight(kg) 6850
Designed Load 10 tons
Wheelbase(mm) 5250
Engine power Weichai 160HP Euro2
Fuel type DieseI
Transmission Manual 8- speed
Brake Air brake
Axle load(front/rear) 4.0 tons / 11.0 tons
Tire 6+1 pcs, 11.00R20 radial tires
Max speed 90km/h
Vehicle Superstructure Parameters
Dump Box Dimension 5400x2200x600
Material High strengthen carbon steel, 4mm side, 6mm bottom
Unloading Method of Dump Box Double cylinders middle lifting
Maximum Dumping Angle ≤ 45°
Back Door Hinge structure , auto open when dumping
Side Opening Door One(1)



FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck

FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck

FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck

Dumper Truck Features & Structures of FAW (First Automobile Works) 4x4 10 ton Dumper Box Dump Truck

Dumper Trucks Tipper Dump Trucks Series

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
