【Chassis Parameters】
Forland cab chassis, condition new, 2 seats, 2600mm wheelbase, Quanchai 46HP Euro 2 dieseI engine, manual 5-speed transmission, 6.00-15 tires, with one spare tire, 1.2 Ton front axle, 2.8-Ton rear axle, air brake, power assist steering, etc.
【Upper Structure Parameters】
Dump box size 2800x1450x350mm, total 4.56 cubic meter box volume; dump box material 3mm side wall, 4mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Model | CLW5040ZZXBJ2 |
| Chassis brand | Foton Forland |
| Wheeldrive | 4x2, LHD |
| New or Used | New |
| Overall dimension(mm) | 4650x1620x2160 |
| Dump box dimension(mm) | 2800x1450x350 |
| Material of dump box | carbon steel, 3mm side, 4mm floor |
| Unloading method of dump box |
middle double cylinder lifting jack |
| Gross weight(kg) | 4128 |
| Curb weight(kg) | 2650 |
| Load Weight(kg) | 2 Ton |
| Wheelbase(mm) | 2600 |
| Engine power | Quanchai 46HP Euro2 |
| Fuel type | DieseI |
| Transmission | Manual 5- speed |
| Brake | Hydraulic brake |
| Axle load(front/rear) | 1.2/2.8 tons |
| Tire | 6+1 pcs, 6.00-15 nylon tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
