Foton 4x4 awd pick up manlift 8m 10m aerial work platform basket car bucket pickup for sale

- Chassis brand:Foton
- Type:4x4 pickup
- 9.5m working height, 360° slewing
- Basket 200kg load, ±90° rotary
- 2 pcs hydraulic outriggers
- Whatsapp/mob:+8618307220638
- Email: [email protected]
- Http://www.cnclwgroup.com
Description
Description

【Chassis Parameters】

Foton 4x4 pick up double cab chassis, condition new, 2+3 seats, 3105mm wheelbase, Cummins 165HP Euro3 dieseI engine, manual 5-speed transmission, 4+1 pcs 265/70R16 radial tires, with one spare tire, 1.3 ton front axle, 1.8 ton rear axle, disc brake, ABS+EBD, power assist steering, Leather multi-function, Bluetooth+airbag+pre tensioned safety belt (rear middle two-point), MP5+GPS+reversing camera/electric air conditioner/high mounted brake light/child lock//reminder of unfastened seat belt (driver only)/, etc.



【Upper Structure Parameters】

Aerial work trucks refer to special vehicles that transport people and equipment to the scene and perform aerial operations. It has straight telescopic arm aerial truck and knuckle arm aerial truck.

  • Knuckle arm boom system, 2 section
  • Maximum working height 9.5 meters
  • Turntable 360° slewing
  • Basket 200kg load, size 1000x760x1100mm,  ±90° rotary
  • Control operation: at turntable seat and in basekt
  • 2 pcs hydraulic outriggers
  • Engineering rotary lights to warn people



Vehicle Basic Specifications
Vehicle Model CLW5030JGKZB2 Maximum Working Height 9.5 meters
Chassis brand FOTON 4x4 pick up New or Used Condition new
Overall dimension 5430x1690x2300mm Cargo Box Dimension  -
Gross weight 3500 kg Rated Weight  -
Curb weight 3050 kg Wheelbase 3105mm
Axle No. 2 Cab Seat No. Double cabin, 2+3
Axle Load 1300/1800 kg Fuel Type Diesel
Engine Cummins ISF2.8 120kW/165HP  Steering System LHD, power aissist steering
Transmission Manual 5 - speed Clutch Single dry clutch plate
Brake Air brake Tire No. 4 +1 pcs
Front/Rear Suspension - Tire Model 265/70R16
Fuel Tank 76 liter Battery 12V
Max speed 90km/h
Superstructures Parameters
Model CLW GKH09 Maximum Working Height 9.5 meters
Boom Type 2-section arm, telescopic arm Maximum Working Radius -
 Basket Dimension 1000x760x1100 mm Slewing Angle 360°
 Basket Load 200kg  Outrigger Two pcs, folding support legs
Basket Slewing ± 90 degree Outrigger Span

-

Operation System

One set at down turntable position,  one set on upper basket.

Safety System

1. Outrigger leveling bubble;

3. Up and Down operation anti-lock, Upper operation on basket & down operation at turntable can't operation at the same time;

4. When people on basket, outrigger operation is locked, can't operate,  to prevent damage happened;

5. Emerngecy pump is installed to prevent emergency situation.



【Aerial Work Truck Customer's Feedback

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
