Foton Auman 270hp 15 ton heavy duty tipper dump truck

- Brand: FOTON
- Wheeldrive: 4x2,LHD
- Load: 15 ton
- Dumper box:5400x2300x800mm
- Engine:Weichai 2700HP
- Whatsapp/Wechat:+8618307220638
- Email:[email protected]
- Http://

Dump truck,also called dumper,tipper truck,is a vehicle that unloads goods by itself by hydraulic or mechanical lift. Also called dump truck. Dumper truck is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and power take-off device. Common dump trucks such as dongfeng dump truck,HOWO dump truck,Foton dump truck,ISUZU dump truck,shacman dump truck,jac dump truck,etc; 4 wheeler garbage dumper,6 wheeler garbage dumper,10 wheeler garbage dumper,12 wheeler garbage dumper; and also have 4x4 dump truck,6x6 dump truck,8x8 garbage dump truck,and also 1 to 100 ton garbage tipper dump trucks, load capcity commonly is 5 ton tipper truck,10 ton garbage tipper truck, 20 ton garbage tipper truck, 40 ton tipper and 100 ton garbage tipper truck.


Cab chassis of Foton Auman 270hp 15t heavy duty tipper dump truck for general merchandise dumper, famous brand FOTON chassis, single half cabin, condition new, 5000mm wheelbase, Weichai WP10.270E32 270HP Euro3 diesel engine, manual 9-speed transmission, 6+1 pcs 11R22.5 tires, with one spare tire, air brake, power assist steering, air conditioning, etc.


【Upper Structure Parameters】

Foton Auman 270hp 15t heavy duty tipper dump truck: Dump box size 5400x2300x800mm;  dump box material: side 4mm, floor 6mm; dump box hydraulic cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.

Vehicle Basic Specifications
Chassis brand FOTON
Wheeldrive 4x2
New or Used New
Overall dimension(mm) 7950x2500x3200
Dump box dimension(mm) 5400x2300x800mm
Curb weight(kg) 18000
Load Weight(kg) 9250
Wheelbase(mm) 5000
Engine power Weichai brand WP10.270E32  270HP Euro3
Fuel type DieseI
Transmission Manual 9- speed
Brake Air brake
Axle 6.5 ton / 13 ton
Tire 6+1 pcs 11R22.5
Max speed 90km/h
Vehicle Superstructure Parameters
Dump Box Dimension 5400x2300x800mm
Material Side: 4mm carbon steel
Floor: 5mm carbon steel plate
Unloading Method of Dump Box Hydraulic lifting cylinder
Maximum Dumping Angle ≤ 45°
Back Door Hinge structure , auto open when dumping
Side Opening Door One(1)

More Reference Pictures of Foton Auman 270hp 15 ton heavy duty tipper dump truck:

Chengli dumper structures of More Reference Pictures of Foton Auman 270hp 15 ton heavy duty tipper dump truck:

Cases of Chengli produced dump truck:

Chengli Special Automobile Co., Ltd. Has a Complete After-sales Service System

In order to make you always satisfied from purchasing, owning and using products, Chengli Special Automobile Co.,Ltd has a nationwide sales and service network to provide you with a full range of services.

◆Training Service

Jiangnan Company provides free expert training for all customers who purchase our products, and the training does not charge any fees.

◆Warranty Commitment

Customers can enjoy up to one year or 25,000 kilometers, and free replacement of parts (excluding wearing parts) damaged due to quality problems during the warranty period. The chassis part is guaranteed by the original factory at the national secondary service station nationwide, and the modified part is provided by our company with the service tenet of the customer being always right, and the service tenet of "customer care and caring for each car". Respond within 12 hours after receiving the letter for help from customers, and do not exceed 24 hours for door-to-door service in inland provinces and cities, and 48 hours for individual areas. Long-term supply of original accessories and accessories to provide accessories at preferential market prices. Overseas customers guarantee to reply within 24 hours and give guidance plan.

◆24 Hours Service

The service tenet is that the customer is always right, the service tenet is to care about the customer and every car, and make a public commitment to the society. , Shanghai, Guangdong, Zhejiang, Fujian, Hainan), no more than 24 hours in inland provinces and cities, and no more than 48 hours in individual areas.

◆Rescue Service

When the customer's vehicle cannot be repaired at the service station due to special reasons, the service station can provide on-site service of vehicles, personnel and accessories to solve the customer's difficulties to the greatest extent and reduce the customer's concerns about using the car.

◆Customer Return Visit

Chengli Special Automobile Co.,Ltd. implements the three-level return visit service of dealers, service stations and return visit consultants, caring about customers, helping customers understand and familiarizing themselves with cars, helping customers to actively digest potential hidden dangers in advance, and improving the effective service life of products. To ensure the interests of customers.

Order Process

     ①: Car purchase negotiation: Contact the vehicle model information parameters by telephone or on-site inspection to discuss the vehicle model, Beiqi Foton remote water supply forest fire truck price and related requirements.

     ②: Signing the contract: Both parties sign the vehicle purchase and sale contract and pay the contract deposit in advance (fax signing of the contract or on-site signing of the contract is acceptable).

     ③: Arrange production: Our company arranges workshop production according to the contract requirements.

     ④: Delivery of the vehicle: The vehicle is delivered and accepted, the balance of the vehicle is paid, and the relevant procedures are completed. For more detailed car booking process, please inquire!

Answers to the Questions that Customers Care About before Purchasing?

(1) Free maintenance plan and period?

1. Tracking service time: lifetime; 2. From the date of delivery to the customer, within the normal range of use, within 20,000 kilometers or within one year of free repair (excluding wearing parts and electrical parts), more than one year, only charge Parts fee; 3. Service arrival time: within the province, arrive within 24 hours; other areas, dispatch personnel within 24 hours; 4. During the annual flood control period, engineers and technicians are scheduled to visit regularly or irregularly to ensure timely failures Excluded, no fault active prevention.

(2) What is the price method of free post-parts supply?

1. Method: unified supply at the local Dongfeng/Jinan Heavy Duty Truck/Isuzu and other chassis technical service stations, according to user requirements or directly delivered by Chengli Special Automobile Factory; 2. Parts are only charged for the cost of production, and no other fees are added.

(3) After-sales service method?

The maintenance of the chassis part can be solved at the service station near the user's place of use. The maintenance of the special device can be done by telephone or fax. The supplier will send professional maintenance personnel to the place of use 24-28 hours after receiving the call from the user.

(4) Technical training program?

The supplier is responsible for free training of equipment users at the user's location before delivering the vehicle to the user, mainly on how to operate the hydraulic system and special devices for the driver to be familiar with the basic principles of this type of vehicle and the ability to deal with general failures.

(5) How to transport and load the vehicle?

According to the dimensions and weight of the vehicle or cargo, you can choose bulk carriers, ro-ro ships, container ships 20GP, 40GP, 40HQ, 40FR, etc.

(6) What is the time to pick up the car at the factory?

Self-pick-up time: Monday to Sunday, 08:00-19:00 (some self-pick-up points work hours from 9:00-18:00, in case of national holidays, the press release time shall prevail. focus on)

(7) Can't we go to China abroad? Want to see the car to see the factory how to do?

We can let users see the general situation of offices, factories, production scenes, and factories through video calls and shooting videos, and help foreign customers understand us. For users who order vehicles, they can watch the vehicle appearance, function demonstration videos, and other details through video inspection, so that users can grasp their order production progress and situation in real time. We will create high-quality and personalized special vehicles for each user according to the actual needs of users. You are welcome to visit the production strength and product technology on the spot, and we will provide you with the best service!


As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
