【Chassis Parameters】
FOTON Aumark cab chassis, condition new, 3 seats, 3360mm wheelbase, Foton Power 108HP Euro 3 dieseI engine, Jiangling 5-speed transmission, 7.00R16 radial tires, with one spare tire, 2.2 Ton front axle, 5-Ton rear axle, air brake, power assist steering, etc.
【Upper Structure Parameters】
Dump box size 3800x2000x600mm, total 4.56 cubic meter box volume; dump box material 3mm side wall, 4mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Model | CLW5080ZZXBJ3 |
| Chassis brand | Sinnotruk HOWO |
| Wheeldrive | 4x2, RHD |
| New or Used | New |
| Overall dimension(mm) | 5820x2150x2320 |
| Dump box dimension(mm) | 3800x2000x600 |
| Material of dump box | carbon steel, 3mm side, 4mm floor |
| Unloading method of dump box |
middle double cylinder lifting jack |
| Gross weight(kg) | 7600 |
| Curb weight(kg) | 3600 |
| Load Weight(kg) | 4 tons |
| Wheelbase(mm) | 3360 |
| Engine power | Foton Power 108HP Euro3 |
| Fuel type | DieseI |
| Transmission | Jiangling 5- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2.2/5 tons |
| Tire | 6+1 pcs, 7.00R16 radial tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
