【Chassis Parameters】
Sinotruk HOWO 6x4 RHD heavy cab chassis, condition new, HW76 new cabin, 3 seats with half sleeper, 3625+1350mm wheelbase, Sinotruk 290HP Euro 3 dieseI engine, HW19710 10-speed transmission, 10+1 pcs 12.00R20 radial tires, with one spare tire, HF9 9 Ton front axle, 2x HC16 16 Ton double reduction rear axle, air brake, power assist steering, with air conditioning, etc.
【Upper Structure Parameters】
Dump box size 5600x2300x800mm, total 10.3 cubic meter box volume; dump box material 6mm side wall, 8mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Model | CLW5250ZZXZ3 |
| Chassis brand | Sinnotruk HOWO |
| Wheeldrive | 6x4, RHD |
| New or Used | New |
| Overall dimension(mm) | 8050x2500x3200 |
| Dump box dimension(mm) | 5600x2300x800 |
| Material of dump box | carbon steel, 6mm side, 8mm floor |
| Unloading method of dump box |
middle double cylinder lifting jack |
| Gross weight(kg) | 31000 |
| Curb weight(kg) | 11200 |
| Load Weight(kg) | 20 tons |
| Wheelbase(mm) | 3625+1350 |
| Engine power | Sinotruk 290HP Euro2 |
| Fuel type | DieseI |
| Transmission | HW19710 manual 10- speed |
| Brake | Air brake |
| Axle load(front/rear) | HF9/2x HC16 tons |
| Tire | 10+1 pcs, 12.00R20 radial tires |
| Max speed | 90km/h |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
