【Chassis Parameters】
ISUZU elf 4x2 chassis, single cabin, condition new, 3360mm wheelbase, ISUZU 98HP diesel engine, MSB-5 manual 5-speed transmission, 7.00R16 radial tires, with one spare tire, 2.0 ton front axle, 4.0 ton rear axle, air brake, power assist steering, exhaust pipe front mounted, etc.
【Upper Structure Parameters】
Dump box size 3600x1900x400mm; dump box material 3mm side wall, 4mm floor plate; dump box middle double cylinder lifting jack, dumping angle 45°; control inside cabin, can lift box, down box, stop box.
| Vehicle Basic Specifications | |
| Model | CLW5060ZZXQ5 |
| Chassis brand | ISUZU |
| Wheeldrive | 4x2 |
| New or Used | New |
| Overall dimension(mm) | 5820x2100x2200 |
| Dump box dimension(mm) | 3600x1900x400mm |
| Gross weight(kg) | 4495 |
| Curb weight(kg) | 2890 |
| Load Weight(kg) | 1500 |
| Wheelbase(mm) | 3360 |
| Engine power | ISUZU 4KH1 98HP |
| Fuel type | DieseI |
| Transmission | Manual 5- speed |
| Brake | Air brake |
| Axle load(front/rear) | 2.0 tons / 4.0 tons |
| Tire | 6+1 pcs, 7.00R16 radial tires |
| Max speed | 90km/h |
| Vehicle Superstructure Parameters | |
| Dump Box Dimension | 3600x1900x400mm |
| Material | High strengthen carbon steel, 3mm side, 4mm bottom |
| Unloading Method of Dump Box | Double cylinders middle lifting |
| Maximum Dumping Angle | ≤ 45° |
| Back Door | Hinge structure , auto open when dumping |
| Side Opening Door | One(1) |
As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
