ISUZU 4.2m 4t Explosives Carrier Blasting equipment fireworks and firecracker transporter box truck

Explosion-proof transport trucks are also known as explosion-proof vehicles, explosives transport vehicles, detonator transport vehicles, civilian explosive equipment transport vehicles, civilian explosive vehicles, fireworks and firecrackers transport trucks.

【Chassis Parameters】

ISUZU 4.2m 4t Explosives Carrier Blasting equipment fireworks and firecracker transporter box truck: The chassis selected by ISUZU NKR 4x2, the original type-II hazardous chemical chassis, with a wheelbase of 3360mm, 7.00R16 steel wire tires, a wide-body cab, the engine is Qingling ISUZU 130 horsepower diesel engine, manual 5-speed gearbox, and an optional air conditioner. Steering assistance, hydraulic brake system, front exhaust pipe (with fire protection), a static belt, speed limit 80km/h.

Chassis brand options: ISUZU Blasting equipment transporter truck, Sinotruk HOWO Blasting equipment transporter truck, Foton Blasting equipment transporter truck, JAC hazard goods transporter, SHACMAN Explosives Transport Box Truck, SAIC-HONGYAN-IVECO Explosives Transport Box Truck, Changan Explosives Transport Box Truck, etc.

【Upper Structure Parameters】

ISUZU 4.2m 4t Explosives Carrier Blasting equipment fireworks and firecracker transporter box truck: box body size 4120x1900x1900mm, the outer plate is made of 1.2MM thick cold-rolled plate. The shutters are formed at one time. The interior is made of aluminum plate with good electrical conductivity, with ventilation holes. The inner lining is a solid and stable rectangular tube skeleton. The four materials are compounded by modern technology. There is a sleeping ring inside to fix the cargo. The car is equipped with a vehicle-specific smoke alarm and a rear door anti-theft device. It has a static belt, a fire extinguisher, and a fire cover. Vehicle national standard reflective signs and warning signs. The main transport medium of the blasting equipment transport vehicle: black powder, compressed black powder, electric detonator, blasting explosive, ignition fuse, special pyrotechnic products, fireworks and firecrackers.

Blasting equipment transporter is also known as explosive transporter, detonator transporter, explosion-proof vehicle, civil explosive vehicle, fireworks and firecracker transporter. It is developed and produced according to the regulations of relevant ministries and commissions of the state for the transportation of blasting equipment and the requirements of users. It has the main functions of high car body strength, fire retardant, rain proof, electrostatic spark prevention, fire alarm and anti-theft alarm.

Configuration and Characteristics of Dangerous Goods Transport Trucks

 ★ Exhaust spark arrester

 For blasting equipment transport vehicles and dangerous goods transport vehicles, the exhaust pipe of the vehicle engine should be forwarded, and an exhaust spark arrester should be installed. It is installed at the end of the exhaust pipe to cool the exhaust gas of the motor vehicle, so as to avoid extinguishing the sparks entrained in the exhaust gas.

 ★ Static conductive rubber drag strip

 The static-conducting rubber drag strip is installed on the chassis of the vehicle, which can introduce static electricity into the ground, so that the box body is always at the zero position to prevent the generation of static sparks.

★ Ionization smoke detector

 The interior of the cargo compartment should have good smoke-sensing alarm performance. When there is smoke, the smoke detector should alarm within 3 minutes. The cab has a built-in alarm device, and the alarm sound intensity is above 100 decibels.

 ★ Static conductive rubber sheet

 The floor of the cargo compartment should be laid with flame-retardant static-conducting rubber sheets, which should be fixed with a static-conducting adhesive. The board should not wrinkle or warp.

★Anti-explosive container

  Anti-explosion containers should be installed in the rear compartment. The thickness of the partition wall should not be less than 80mm. The interlayer of the wall should be filled with non-combustible (or flame-retardant) materials that can absorb the energy of the explosion shock wave; when installing the anti-explosion container, the position of the explosion vent should avoid confrontation with the important parts of the vehicle chassis.

★Ventilation windows, vents

  The ventilation window is pressed and formed by a special mold at one time, which has the functions of rainproof and ventilation. The air vents are installed on the inner wall of the side compartment corresponding to the ventilation windows to ensure air circulation in the compartment.

 ★Warning signs

  The outside of the cargo box should also be painted with safety notices, diamond-shaped explosives, hazard indicators, orange explosion characters, etc. to facilitate identification and discovery by other personnel.

 ★Anti-theft alarm and box skin

The inner skin material of the cargo compartment shall be made of flame-retardant materials that do not cause sparks when impacted. Non-ferrous metal materials or marine plywood can be used, and the inner surface of marine plywood shall be coated with fire-retardant paint. The gap between the inner and outer skins of the cargo compartment shall be filled with flame-retardant and heat-insulating materials, and the outer side of the metal outer skin shall be sprayed with light-colored paint. In addition, there is an anti-theft alarm device on the door frame to ensure the safety of the compartment.




Foton 6-8 ton hazardous goods box truck

Dongfeng KR 10-15 ton hazardous goods box truck

Yuejin mass order of hazardous goods box trucks

JMC mass order of high fence hazardous goods trucks

Dongfeng mass order of high fence hazardous goods trucks

Chengli Special Automobile Co., Ltd. Has a Complete After-sales Service System

In order to make you always satisfied from purchasing, owning and using products, Chengli Special Automobile Co.,Ltd has a nationwide sales and service network to provide you with a full range of services.

◆Training Service

Jiangnan Company provides free expert training for all customers who purchase our products, and the training does not charge any fees.

◆Warranty Commitment

Customers can enjoy up to one year or 25,000 kilometers, and free replacement of parts (excluding wearing parts) damaged due to quality problems during the warranty period. The chassis part is guaranteed by the original factory at the national secondary service station nationwide, and the modified part is provided by our company with the service tenet of the customer being always right, and the service tenet of "customer care and caring for each car". Respond within 12 hours after receiving the letter for help from customers, and do not exceed 24 hours for door-to-door service in inland provinces and cities, and 48 hours for individual areas. Long-term supply of original accessories and accessories to provide accessories at preferential market prices. Overseas customers guarantee to reply within 24 hours and give guidance plan.

◆24 Hours Service

The service tenet is that the customer is always right, the service tenet is to care about the customer and every car, and make a public commitment to the society. , Shanghai, Guangdong, Zhejiang, Fujian, Hainan), no more than 24 hours in inland provinces and cities, and no more than 48 hours in individual areas.

◆Rescue Service

When the customer's vehicle cannot be repaired at the service station due to special reasons, the service station can provide on-site service of vehicles, personnel and accessories to solve the customer's difficulties to the greatest extent and reduce the customer's concerns about using the car.

◆Customer Return Visit

Chengli Special Automobile Co.,Ltd. implements the three-level return visit service of dealers, service stations and return visit consultants, caring about customers, helping customers understand and familiarizing themselves with cars, helping customers to actively digest potential hidden dangers in advance, and improving the effective service life of products. To ensure the interests of customers.

Order Process

     ①: Car purchase negotiation: Contact the vehicle model information parameters by telephone or on-site inspection to discuss the vehicle model, Beiqi Foton remote water supply forest fire truck price and related requirements.

     ②: Signing the contract: Both parties sign the vehicle purchase and sale contract and pay the contract deposit in advance (fax signing of the contract or on-site signing of the contract is acceptable).

     ③: Arrange production: Our company arranges workshop production according to the contract requirements.

     ④: Delivery of the vehicle: The vehicle is delivered and accepted, the balance of the vehicle is paid, and the relevant procedures are completed. For more detailed car booking process, please inquire!

Answers to the Questions that Customers Care About before Purchasing?

(1) Free maintenance plan and period?

1. Tracking service time: lifetime; 2. From the date of delivery to the customer, within the normal range of use, within 20,000 kilometers or within one year of free repair (excluding wearing parts and electrical parts), more than one year, only charge Parts fee; 3. Service arrival time: within the province, arrive within 24 hours; other areas, dispatch personnel within 24 hours; 4. During the annual flood control period, engineers and technicians are scheduled to visit regularly or irregularly to ensure timely failures Excluded, no fault active prevention.

(2) What is the price method of free post-parts supply?

1. Method: unified supply at the local Dongfeng/Jinan Heavy Duty Truck/Isuzu and other chassis technical service stations, according to user requirements or directly delivered by Chengli Special Automobile Factory; 2. Parts are only charged for the cost of production, and no other fees are added.

(3) After-sales service method?

The maintenance of the chassis part can be solved at the service station near the user's place of use. The maintenance of the special device can be done by telephone or fax. The supplier will send professional maintenance personnel to the place of use 24-28 hours after receiving the call from the user.

(4) Technical training program?

The supplier is responsible for free training of equipment users at the user's location before delivering the vehicle to the user, mainly on how to operate the hydraulic system and special devices for the driver to be familiar with the basic principles of this type of vehicle and the ability to deal with general failures.

(5) How to transport and load the vehicle?

According to the dimensions and weight of the vehicle or cargo, you can choose bulk carriers, ro-ro ships, container ships 20GP, 40GP, 40HQ, 40FR, etc.

(6) What is the time to pick up the car at the factory?

Self-pick-up time: Monday to Sunday, 08:00-19:00 (some self-pick-up points work hours from 9:00-18:00, in case of national holidays, the press release time shall prevail. focus on)

(7) Can't we go to China abroad? Want to see the car to see the factory how to do?

We can let users see the general situation of offices, factories, production scenes, and factories through video calls and shooting videos, and help foreign customers understand us. For users who order vehicles, they can watch the vehicle appearance, function demonstration videos, and other details through video inspection, so that users can grasp their order production progress and situation in real time. We will create high-quality and personalized special vehicles for each user according to the actual needs of users. You are welcome to visit the production strength and product technology on the spot, and we will provide you with the best service!

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
