ISUZU elf 4cbm Garbage Compactor Truck

ISUZU 4x2 98HP trash compactor truck
MSB 5-speed transmission
Tire: 6+1 pcs, 7.00R16
Volume: 4m3 volume, 3mm side wall, 4mm bottom plate
Rear waste bin flip device, intelligent control system+manual control+inside cab controlled
Description
Description

【Chassis Parameters】

Famous brand ISUZU elf single cab chassis, condition new, 3360mm wheelbase, Qingling ISUZU 98HP dieseI engine, MSB 5-speed transmission, 7.00R16 tires, with one spare tire, 2.5 ton front axle, 4.8 ton rear axle, power assist steering, with air conditioning, etc.



【Upper Structure Parameters】

Chengli produced trash compactor body, with 4 cubic meter volume box, rear with waste bin flip device, can flip 120L/240L/660L waste bins, control panel+manual lever+inside cab controlled.



Model CLW5070ZYSQ5
Chassis brand ISUZU
Wheeldrive 4x2 or 4x4, LHD
New or Used New
Overall dimension 7350x2500x2850mm
Gross weight 7300kg
Curb weight 4300kg
Load 3 tons
Wheelbase 3360mm
Engine power Qingling ISUZU 98HP
Fuel type DieseI
Transmission MSB 5-speed manual gearbox
Brake hydraulic brake
Axle load 2.4 ton / 4.5 ton
Tire 6+1 pcs, 7.00R16 tires
Max speed 90km/h



【Structures & Features of Chengli Garbage Compactor】

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
