ISUZU NQR/600P Sewer Dredging Truck

- Brand:ISUZU
- Engine: ISUZU 98hp/120hp
- Dumper Body: 3.5cbm
- Dredging depth: 10 meter
- Dredging bucket voluem:0.075m3
- Whatsapp:+8618307220638
- Email: [email protected]
- http://www.cnclwgroup.com
Description
Description

【Chassis Parameters】

Cab chassis of ISUZU NKR/100P 4000 liter Vacuum Toilet Sewage Suction Truck: ISUZU NKR/100P cab chassis, condition new, 3360mm wheelbase, Qingling ISUZU 98HP or 120HP dieseI engine, manual 5-speed transmission, 7.00R16 raidal tires, with one spare tire, 2.5 ton front axle, 4.8 ton rear axle, hydraulic brake, power assist steering, with air conditioning, etc.

【Upper Structure Parameters】

Grab dredger truck produced by Chengli Special Automobile Co., Ltd. is also known as the dredger, sludge grab, hydraulic grab excavator, inspection well dredger, and sewer dredger.

The dredger is mainly composed of chassis, dump truck body and sludge grab. There are main boom lifting, main boom rotation, grab bucket grasping, rope pipe winding, tipper lifting, body support and other devices.


Superstructure Configuration: The rear of the cargo box is designed with a fixed slope. The vehicle is equipped with a two lobe slideway hydraulic manipulator, hydraulic pipe with steel wire, high pressure resistance, a multi way valve with wire rope synchronous auxiliary function, a 150 liter water tank, and a 120 watt electric water pump to facilitate the self cleaning of the vehicle. The manipulator has a drop depth of 8/10 meters.

Model CLW5070ZTWQ5
Chassis brand ISUZU
Wheeldrive 4x2, LHD
New or Used New
Overall dimension 5995x2100x2980mm
Gross weight 7300kg
Curb weight 3850kg
Load 4-5 ton
Wheelbase 3360mm
Engine power Qingling ISUZU 4KH1 98HP or 120HP options
Fuel type DieseI
Transmission Manual, 5-Forward and 1-Reverse
Brake Full air brake
Axle load 2.5 ton / 4.8 ton
Tire 6+1 pcs,7.00R16 radial tires
Max speed 90km/h
Performance Dump Body 3.5 m3, hydraulic lifting for unloading
Crane 2 ton hydraulic crane
Dredging depth 8-10 meter
Working radius 1 ~ 1.2 meter
Dredging bucket volume 0.075 m3
Operation method Manual + remote control

 【Designs & Drawing of Dredging Truck】


All devices are powered by the automobile engine. The power take-off drives the oil pump, hydraulic motor, oil cylinder, valve and other hydraulic transmission systems. One person can easily operate the handle to achieve all tasks of mechanized digging, extraction, loading and unloading of inspection well sewage.

The optional size of two grab buckets produced by Chengli Special Automobile Co., Ltd. can be freely replaced according to the excavation site. Each grab bucket is composed of four claw pieces, which are released in lotus shape. When only two symmetrical claw pieces are used to work in the clamp mode, it can easily grasp solid objects in the shape of long strips, cylinders, boulders, etc.

In addition, the dredger is clean and free of dead space. It is convenient, safe and reliable to operate, time-saving, labor-saving, and efficient. There is no stain left at the work site, which reduces secondary pollution and is beneficial to environmental protection.


【Structures of Desilting Dredging Truck】

Functional characteristics of the desilting vehicle produced by Chengli Special Automobile Co., Ltd

1. Strong adaptability: adapt to the cleaning of sediment in any harsh environment, such as kiln well, debris pool, oil pool, biogas pool and septic tank.

2. Large excavation depth: the maximum excavation depth is 10 meters, the working range of the manipulator is 1000-1200, the volume is 0.075 cubic meters, and the dredging rate is 95%

3. Large amount of self unloading: the volume of the dredger car is 3.5 cubic meters, the U shape is bucket type, and the bottom is designed with a double cylinder three arm hydraulic top, which has a long service life, a large lifting angle, and the garbage can be completely unloaded during self unloading.

4. Good structural performance: the slideway manipulator runs up and down without friction, with low energy consumption and long service life.

5. Operation mode: manual operation and wireless operation, realizing simple engineering operation, safety and reliability, time saving and labor saving, and high efficiency.

6. The dredger is equipped with a two valve hydraulic slideway manipulator, which can be freely replaced according to the excavation environment. The equipment is also applicable to the removal of sludge, sand, stone, bricks and other sediments in the production and domestic waste of urban and rural factories, water pools, oil pools, biogas tanks, septic tank inspection wells.

【Job Scenes of Dredging Truck】

Chengli Special Automobile Co., Ltd. Has a Complete After-sales Service System

In order to make you always satisfied from purchasing, owning and using products, Chengli Special Automobile Co.,Ltd has a nationwide sales and service network to provide you with a full range of services.

◆Training Service

Jiangnan Company provides free expert training for all customers who purchase our products, and the training does not charge any fees.

◆Warranty Commitment

Customers can enjoy up to one year or 25,000 kilometers, and free replacement of parts (excluding wearing parts) damaged due to quality problems during the warranty period. The chassis part is guaranteed by the original factory at the national secondary service station nationwide, and the modified part is provided by our company with the service tenet of the customer being always right, and the service tenet of "customer care and caring for each car". Respond within 12 hours after receiving the letter for help from customers, and do not exceed 24 hours for door-to-door service in inland provinces and cities, and 48 hours for individual areas. Long-term supply of original accessories and accessories to provide accessories at preferential market prices. Overseas customers guarantee to reply within 24 hours and give guidance plan.

◆24 Hours Service

The service tenet is that the customer is always right, the service tenet is to care about the customer and every car, and make a public commitment to the society. , Shanghai, Guangdong, Zhejiang, Fujian, Hainan), no more than 24 hours in inland provinces and cities, and no more than 48 hours in individual areas.

◆Rescue Service

When the customer's vehicle cannot be repaired at the service station due to special reasons, the service station can provide on-site service of vehicles, personnel and accessories to solve the customer's difficulties to the greatest extent and reduce the customer's concerns about using the car.

◆Customer Return Visit

Chengli Special Automobile Co.,Ltd. implements the three-level return visit service of dealers, service stations and return visit consultants, caring about customers, helping customers understand and familiarizing themselves with cars, helping customers to actively digest potential hidden dangers in advance, and improving the effective service life of products. To ensure the interests of customers.

Order Process

     ①: Car purchase negotiation: Contact the vehicle model information parameters by telephone or on-site inspection to discuss the vehicle model, Beiqi Foton remote water supply forest fire truck price and related requirements.

     ②: Signing the contract: Both parties sign the vehicle purchase and sale contract and pay the contract deposit in advance (fax signing of the contract or on-site signing of the contract is acceptable).

     ③: Arrange production: Our company arranges workshop production according to the contract requirements.

     ④: Delivery of the vehicle: The vehicle is delivered and accepted, the balance of the vehicle is paid, and the relevant procedures are completed. For more detailed car booking process, please inquire!

Answers to the Questions that Customers Care About before Purchasing?

(1) Free maintenance plan and period?

1. Tracking service time: lifetime; 2. From the date of delivery to the customer, within the normal range of use, within 20,000 kilometers or within one year of free repair (excluding wearing parts and electrical parts), more than one year, only charge Parts fee; 3. Service arrival time: within the province, arrive within 24 hours; other areas, dispatch personnel within 24 hours; 4. During the annual flood control period, engineers and technicians are scheduled to visit regularly or irregularly to ensure timely failures Excluded, no fault active prevention.

(2) What is the price method of free post-parts supply?

1. Method: unified supply at the local Dongfeng/Jinan Heavy Duty Truck/Isuzu and other chassis technical service stations, according to user requirements or directly delivered by Chengli Special Automobile Factory; 2. Parts are only charged for the cost of production, and no other fees are added.

(3) After-sales service method?

The maintenance of the chassis part can be solved at the service station near the user's place of use. The maintenance of the special device can be done by telephone or fax. The supplier will send professional maintenance personnel to the place of use 24-28 hours after receiving the call from the user.

(4) Technical training program?

The supplier is responsible for free training of equipment users at the user's location before delivering the vehicle to the user, mainly on how to operate the hydraulic system and special devices for the driver to be familiar with the basic principles of this type of vehicle and the ability to deal with general failures.

(5) How to transport and load the vehicle?

According to the dimensions and weight of the vehicle or cargo, you can choose bulk carriers, ro-ro ships, container ships 20GP, 40GP, 40HQ, 40FR, etc.

(6) What is the time to pick up the car at the factory?

Self-pick-up time: Monday to Sunday, 08:00-19:00 (some self-pick-up points work hours from 9:00-18:00, in case of national holidays, the press release time shall prevail. focus on)

(7) Can't we go to China abroad? Want to see the car to see the factory how to do?

We can let users see the general situation of offices, factories, production scenes, and factories through video calls and shooting videos, and help foreign customers understand us. For users who order vehicles, they can watch the vehicle appearance, function demonstration videos, and other details through video inspection, so that users can grasp their order production progress and situation in real time. We will create high-quality and personalized special vehicles for each user according to the actual needs of users. You are welcome to visit the production strength and product technology on the spot, and we will provide you with the best service!

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest price!
