JAC 4x2 14ft Refrigerated Truck

- JAC 4~6 Tons Refrigerated Truck
- Insulation Box: 4100x2000x2200mm
- Refrigeration unit: -16℃ ~ 0℃
- Cummins 125HP Euro3 engine
- 6+1 pcs 7.00R16 radial tires
Description
Description

【Chassis Parameters】

JAC cab chassis, condition new, 3 seats, 3360mm wheelbase, Cummins 125HP Euro 3 dieseI engine, WLY 6-speed transmission, 7.00R16 radial tires, with one spare tire, 2.5 Ton front axle, 5 Ton rear axle, air brake, power assist steering, etc.

Chassis brand options: Dongfeng, Sinotruk HOWO, Foton, JAC, SHACMAN, SAIC-HONGYAN-IVECO, etc.



【Upper Structure Parameters】

Insulation box size 4100x2000x2200mm, total 18 cbm box volume;  insulation box material outer and inner plate are FRP panel, middle with 80mm insulation layer; Refrigeration unit is China famous brand -16℃ capacity.

Refrigeration unit brand options: American import brand Thermo King, Carrier brand;   China brand Hanxue, Kauxue, Huatai, Bingli, etc.



Model CLW5071XLCHF3
Chassis brand JAC
Wheeldrive 4x2
New or Used New
Overall dimension(mm) 5995x2200x3200
Insulation box dimension(mm) 4100x2000x2200
Material of Insulation box Sanwitch structure: FRP panel + 80mm insulation + FRP panel
Refrigeration unit
Cihna famous brand -16℃~ 0 ℃
Gross weight(kg) 7300
Curb weight(kg) 2860
Load Weight(kg) 4 ~ 6 tons
Wheelbase(mm) 3360
Engine power Cummins 125HP Euro3
Fuel type DieseI
Transmission WLY 6- speed
Brake Air brake
Axle load(front/rear) 2.5 tons / 5 tons
Tire 6+1 pcs, 7.00R16 radial tires
Max speed 90km/h



As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
