【Chassis Parameters】
Chassis of Powerplus Fuel Tank Truck: powerplus 6x4 chassis, condition new, 4350+1350mm wheelbase, Weichai 300HP or 340HP Euro2 diesel engine, Shaanxi Fast 10-speed transmission, 12.00R20 radial tires, with one spare tire, Man 7.5 ton front axle, 2x Man 16 ton rear axle, air brake, power assist steering, air brake, exhaust pipe front mounted, with air conditioning, etc.
【Upper Structure Parameters】
Chengli oil tanker, oil tanker: also known as mobile refueling truck, fuel tank truck, fuel tanker truck, computer tax-controlled refueling truck, oil tanker, oil loading truck, oil truck, oil truck, oil transporter, edible oil transporter, mainly used for oil Transportation and storage of derivatives (gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products). According to different uses and use environments, it has a variety of refueling or oil transportation functions, including oil absorption, pumping oil, and various oil packaging and distribution functions.
Chengli fuel tank truck capacity: chengli produced fuel tanker volume from 1000 liter to 60000 liter, tanker truck, tanker trailer, tanker container, etc. We accept customzied services and designeds.
Chengli fuel tank truck has: dongfeng fuel tank truck,howo fuel tanker,shacman oil tanker truck,isuzu fuel tanker truck,foton fuel tank truck,iveco fuel truck,jac oil tank truck,etc.
【Vehicle Basic Parameters】
| Vehicle Basic Specifications |
|||
| Vehicle Model | CLW5250GJYSX2 | Volume of Tanker | 20000 liter |
| Chassis brand | Powerplus 6x4 | New or Used | Condition new |
| Overall dimension | 9850x2500x3050mm | Cargo Box Dimension | - |
| Gross weight | 31000 kg | Rated Weight | 20800 kg |
| Curb weight | 10200 kg | Wheelbase | 4350+1350mm |
| Axle No. | 3 | Cab Seat No. | 3 people, with a sleeper |
| Axle Load | 7500/2x 16000 (kg) | Fuel Type | Diesel |
| Engine |
Wechai 300HP or 340HP Euro2 |
Steering System | LHD, power aissist steering |
| Transmission | Manual, HW19710 10-speed | Clutch | Single dry clutch plate |
| Brake | Air brake | Tire No. | 10 +1 pcs |
| Front/Rear Suspension | Multi Leaf Springs | Tire Model | 12.00R20 radial tires |
| Fuel Tank | 400 liter | Battery | 24V |
| Max speed | 90km/h |
||
| Superstructures Parameters |
|||
| Type | Fuel Transport Tanker | Volume of Tanker | 20,000 liter |
| Medium | Gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products | Material of Tanker | Carbon steel |
| Manhole | 2 pcs, aluminum alloy manhole cover | Fuel Discharge Valve |
2 pcs |
| Safety Valve | Bottom emergency cut off valve, breathing valve, anti-overflow probe | Pump |
1 unit, 60/90 fire pump Pump inlet and pump outlet |
|
Flow Meter |
Optional | Level Guage | Optional |
| Refueling Device |
Refueling nozzle with 15 meter thick hose reel (optional) |
||
| Safety System |
1. Foot emergency cut-off valve; 2. Breathing valve; 3. Anti-overflow probe; 4. Static conductive wire reel; 5. Fire extinguisher. |
||
