SHACMAN 20-25 Tons Self Loading Flat bed Truck Excavator Carrier Self Loader

- SHACMAN 20-25 tons Excavator Flatbed Truck
- Weichai 340HP or Cummins 345HP Diesel engine
- 10+1 pcs 12.00R20 radial tires
- Flat bed dimension: 8000x2500, 3000(mm)
- Spring ladder: Hydraulic spring ladders

【Chassis Parameters】

SHACMAN 10 wheeler 20~25 tons self loading flatbed truck adapts SAIC-IVECO-Hongyan dedicated chassis, condition new, 3 seats with a sleeper, 5000mm wheelbase, YUCHAI 180HP or 245HP dieseI engine, Fast 8-speed transmission, 10.00R20 radial tires, with one spare tire, 5.5 ton front axle, 10 ton rear axle, air brake, power assist steering, with air conditioning, etc.

【Upper Structure Parameters】

SHACMAN 10 wheeler 20~25 tons excavator self loading flatbed truck, 8000x2500mm flat bed deck dimension, width can extend to 3 meters; can choose with hydraulic lift outriggers leg installed behind cabin, 30 ton, 40 tons lift capacity, which can be used to lift the flatbed truck to make a ramp of the flat deck bed, for a easy climb or loading onboard for excavators or cars or machines. It is mainly used for carrying excavator, bulldozer, loaders, road rollers, large agricultural machinery, etc. Traditional flatbed truck with two pcs ladders for climbing up, but is very dangerous and for some crawler-type or large machinery is prone to rollover due to the corners of the platform and ladder when getting on the vehicle. Chengli CLW produced self loading flatbed truck, installed a heavy lifting front outrigger at front of flatbed, behind cabin,  it can lifting the truck to give the flat deck plate a tilt angle, so that any truck or machinery can easily climb onto the flat bed,  and on the front of the deck bed, can install hydraulic winch, 5 tons, 8 tons, 10 tons, 20 tons to pull up fault vehicles or machines.


Model CLW5250TPBSX2
Chassis brand SHACMAN
New or Used New
Overall dimension(mm) 11400x2500x3250
Flatbed dimension(mm) 8000x2500,3000
Gross weight 25000kg
Curb weight 9800kg
Load 20-25 tons
Wheelbase(mm) 5775+1400
Engine power Weichai 340HP or Cummins 345HP engine
Fuel type DieseI
Transmission Fast 10 - speed
Brake Full air brake
Axle load MAN 7.5T / 2x MAN 16T
Tire 10+1 pcs, 12.00R20 tires
Max speed 90km/h

- Dimension: 8000x2500, 3000mm

- Material: 8mm deck plate, under supported with 120x120mm square tube made frame

- Rear ladder: 2 pcs hydraulic spring ladders(can choose hydraulic ladders)


[Multi-directional Images]

As vehicles change or emission standards upgraded, the specifications above are for reference. Please contact us for a latest quote!
